Tt-at4 automatic quadruple strain control triaxial instrument is further improved and developed on the basis of conventional triaxial instrument. The purpose is to improve the triaxial test efficiency and reduce the occupation of space, so that the triaxial test and special project test into a conventional geotechnical test. Therefore, the instrument has compact structure, small volume, convenient operation, stable performance, high degree of automation data acquisition and processing functions.
The vertical loading system controlled by stepping motor; Pressure chamber; Multifunctional triaxial tester side pressure control and back pressure control device; Load sensor, pore pressure sensor, volume change sensor, displacement sensor; Master control cabinet; Data acquisition and pore pressure sensors, volume change sensors, displacement sensors; Master control cabinet; Data acquisition and processing system.
 |
 |
 |
 |
